Features:
1. High pressure storage tank (testing pressure=9bar)
2. No vent and less heat loss as compared to low pressure model
3. Highly efficient heat pipe technology
4. No water introduced into vacuum tube
5. No sealing rubber is needed and hence no leaking problem
6. Easy plug-in installation
7. Anti-freeze.
Key specifications:
1) Tube Specification: Φ 58 × 1, 800mm with heat pipe, resistance cold -35
2) Three-layer concentric borosilicate glass tubes
3) Inner tank: SUS304 -2B, thickness: 1.2mm
4) Outer tank: Stainless steel, thickness: 0.41mm
5) Insulating layer is high dense polyurethane foam, thickness: 55mm
6) Brackets are stainless steel for both flat and inclined roof, thickness: 1.2mm
7) Max pressure: 0.6MPa
Features:
1. High pressure storage tank (testing pressure=9bar)
2. No vent and less heat loss as compared to low pressure model
3. Highly efficient heat pipe technology
4. No water introduced into vacuum tube
5. No sealing rubber is needed and hence no leaking problem
6. Easy plug-in installation
7. Anti-freeze.
Key specifications:
1) Tube Specification: Φ 58 × 1, 800mm with heat pipe, resistance cold -35
2) Three-layer concentric borosilicate glass tubes
3) Inner tank: SUS304 -2B, thickness: 1.2mm
4) Outer tank: Stainless steel, thickness: 0.41mm
5) Insulating layer is high dense polyurethane foam, thickness: 55mm
6) Brackets are stainless steel for both flat and inclined roof, thickness: 1.2mm
7) Max pressure: 0.6MPa
