Non-Pressure residential compact Solar Water Heater

Quantity:
  • SP470-58/1800-15
  • Compact Type
  • Stainless Steel
  • Tank Insulation
  • Sunpower or OEM
  • Non Pressure Solar Water Heater
  • CE, Solar Keymark, CCC, ISO9001
  • sunpower
  • China
  • >200L
  • Unpressurized
  • Glass Vacuum Tube
  • CE, ISO9001, CCC
  • Spc470-58/1800
  • SUS304
  • 50L ~300L
  • En12976 Standard
  • 8419191000

Non-Pressure Solar Water Heater CE Approved
Non-Pressure Solar Water Heater CE Approved
Non-Pressure Solar Water Heater CE Approved
Specification:
Outer tank :  diameter 470mm, 0.4mm thickness stainless steel or color steel
Inner tank: diameter 360mm, 0.4mm or 0.5mm or 0.6mm thickness SUS304 food grade stainless steel
Insulation: 55mm thickness polyurethane
Frame: stainless steel or galvanized steel or aluminum alloy
Vacuum tube: common or three targets 58/1800 or 47/1500 vacuum tube
Heat preservation: 72 hours
Hail resistance: 25mm

Feature
1.It is one of the  most common used  compact solar water heating system
2.Can be used for household, hotel, hospital, project application etc.
3.It has  simple structure and working principle  but is the  most economical.
4.easy to be installed on the roof to get enough  water flow pressure
5.The compact system is  non-pressurized,  water flow depending on g ravity water head.
6.This system matched with vacuum tube solar collector
7 . An assistant tank  can be chosen for the tank, having water supplement
